| Model Type | Voltage | Power | Light Effect | CRI | Color Temp | Emergency | Battery |
|---|---|---|---|---|---|---|---|
| LM-COD01-C01 | AC110-220V DC24V |
16~40W | 100Lm/W | >80 | 2700K~5600K | - | - |
| LM-COD01-C02 | AC110-220V DC24V |
16~40W | 100Lm/W | >80 | 2700K~5600K | 3W | - |
| LM-COD01-C03 | AC110-220V DC24V |
16~40W | 100Lm/W | >80 | 2700K~5600K | - | - |
| LM-COD01-C04 | AC110-220V DC24V |
16~40W | 100Lm/W | >80 | 2700K~5600K | 3W | - |
| LM-COD01-C05 | AC110-220V DC24V |
16~40W | 100Lm/W | >80 | 2700K~5600K | - | Ømm |
Product Features
- High brightness, uniform lighting
- High quality marine grade life luminaire
- Fast startup, no stroboscopic, no noise
- Anti radio interference
- More than 50% energy-saving
Product Dimensions (mm)
| Model Type | Dimensions |
|---|---|
| LM-COD01-C01 | 690×23×14 |
| LM-COD01-C02 | 690×23×14 |
| LM-COD01-C03 | 690×23×15 |
| LM-COD01-C04 | 690×23×15 |
| LM-COD01-C05 | 690×23×14 |
Protection Class
IP65
Ambient Temp
-35℃ to 55℃
Tone
Warm light / White light
Material
Metal
Installation
Ceiling Type
Cable Entry
PG19
Lifespan
50,000H
Customization
Color temperature
| Model Type | Voltage | Power | Light Effect | CRI | Color Temperature |
|---|---|---|---|---|---|
| LM-CDD02-F01 | DC10-50V / AC110-220V | 10W / 20W | 100Lm/W | >80 | 2700K~6500K |
| LM-CDD03-E01 | AC110-220V | 40W / 80W / 120W / 180W / 200W | 100Lm/W | >80 | 2700K~6500K |
Product Features
- High brightness, uniform lighting
- High quality marine long life luminaire
- Fast startup, no stroboscopic, no noise
- Anti radio interference
- More than 50% energy-saving
Protection Class
IP65
Tone
Warm light / White light
Material
Coated Metal / Alloy / PC
Installation
Engine room roof / Comfort top
Certification
CCS
Lifespan
50,000H
